　　產品特性

　　常見成品顏色圖片: 紅色　　墻身型: 單壁　　彎曲率: 2:1　　熱縮管可燃性內型: 阻燃材料　　工作中溫度比率(°C): -55 – 135　　工做電壓電流(極大值)：0.6kV　　靈敏性：半撓性, 撓性　　修復的厚度(公差) (mm) ：.08, .12, .15, .16, .2, .23, .25, .31, .36, .38, .51, .64　　治愈的管壁(公差) (in) ： .003, .005, .006, .007, .008, .009, .01, .012, . 013, .014, .015, .02, .025　　還原的管壁(標稱) (mm) ： .4, .43, .5, .51, .64, .76, .88, .89, 1.01, 1.14, 1.27, 1.4　　回復的厚度(標稱) (in) ： .016, .017, .02, .025, .03, .035, .04, .045, .05, . 055　　服務粗度 (mm)：12.7, 25.4, 30, 33, 38, 38.1, 40, 50, 50.8, 57.15, 60, 63.5, 75, 80, 120, 250, 342, 514.35, 556, 570, 640, 675, 1220　　食品長 (in)“ .5, 1, 1.181, 1.299, 1.496, 1.5, 1.575, 1.969, 2, 2.25, 2.362, 2.5, 2.953, 3.15, 4.724, 9.843, 13.464, 20.25, 21.89, 22.441, 25.197, 26.574, 48.03, 48.031　　原直徑(較小值) (mm)” .56, .81, 1.17, 1.6, 2.36, 3.17, 4.74, 6.35, 9.5, 12.7, 19.05, 25.4, 31.75, 38.1, 50.8, 76.2, 101.6　　初始直徑(最高值) (in) .022, .032, .046, .063, .093, .125, .187, .25, . 374, .375, .5, .75, 1, 1.25, 1.5, 2, 3, 4　　抽縮后公稱直徑(最大的值) (mm) .33, .4, .58, .79, 1.17, 1.57, 2.36, 3.17, 4.74, 6.35, 9.5, 12.7, 15.88, 19.05, 25.4, 38.1, 50.8　　收宿后公稱直徑(極限值) (in) .013, .016, .023, .031, .046, .062, .093, .125, . 187, .25, .374, .5, .625, .75, 1, 1.5, 2　　熱縮管尺寸區域 (mm) .58 - 1.17, .79 - 1.6, 1.17 - 2.36, 1.57 - 3.17, 2.36 - 4.74, 3.17 - 6.35, 4.74 - 9.5, 6.35 - 12.7, 6.4 - 12.7, 9.5 - 19.05, 12.7 - 25.4, 15.88 - 31.75, 19.05 - 38.1, 25.4 - 50.8, 38.1 - 76.2, 50.8 - 101.6　　熱縮管規格尺寸條件 (in) .023 - .046, .031 - .063, .046 - .093, .062 - . 125, .093 - .187, .125 - .25, .187 - .374, .25 - . 5, .374 - .75, .5 - 1, .625 - 1.25, .75 - 1.5, 1 - 2, 1.5 - 3, 2 - 4

　　型號：

型號	Marketing Part Number	原始內徑（最小值）	收縮后內徑（最大值)	封裝方法	熱縮管尺寸范圍
RNF-100-1/2-BK-FSP	NB12724001	12.7 mm	6.35 mm	Reel	6.4 – 12.7 mm
RNF-100-1/2-BK-SP	NB12744001	12.7 mm	6.35 mm	Reel	6.4 – 12.7 mm
RNF-100-1/2-BK-STK	NB12762001	12.7 mm	6.35 mm	袋和盒	6.4 – 12.7 mm
RNF-100-1/2R-BK-STK	NB12892001	12.7 mm	6.35 mm	袋和盒	6.4 – 12.7 mm
RNF-100-1-BK-FSP	NB13034001	25.4 mm	12.7 mm	Reel	12.7 – 25.4 mm
RNF-100-1-BK-SP	NB13044001	25.4 mm	12.7 mm	Reel	12.7 – 25.4 mm
RNF-100-1-BK-STK	NB13052001	25.4 mm	12.7 mm	袋和盒	12.7 – 25.4 mm
RNF-100-3/4-BK-FSP	NB13264001	19.05 mm	9.5 mm	Reel	9.5 – 19.05 mm
RNF-100-3/4-BK-SP	NB13274001	19.05 mm	9.5 mm	Reel	9.5 – 19.05 mm
RNF-100-3/4-BK-STK	NB13282001	19.05 mm	9.5 mm	袋和盒	9.5 – 19.05 mm
RNF-100-3/4R-BK-STK	NB13392001	19.05 mm	9.5 mm	袋和盒	9.5 – 19.05 mm
RNF-100-3/8-BK-FSP	NB13504001	9.5 mm	4.74 mm	Reel	4.74 – 9.5 mm
RNF-100-3/8-BK-SP	NB13524001	9.5 mm	4.74 mm	Reel	4.74 – 9.5 mm
RNF-100-3/8-BK-STK	NB13542001	9.5 mm	4.74 mm	袋和盒	4.74 – 9.5 mm
RNF-100-3/64-BK-STK	NB15492001	1.17 mm	.58 mm	袋和盒	.58 – 1.17 mm
RNF-100-1-1/2-BK-SP	NB17914001	38.1 mm	19.05 mm	Reel	19.05 – 38.1 mm
RNF-100-1-1/2-BK-STK	NB17932001	38.1 mm	19.05 mm	袋和盒	19.05 – 38.1 mm
RNF-100-1-1/4-BK-SP	NB18084001	31.75 mm	15.88 mm	Reel	15.88 – 31.75 mm
RNF-100-1-1/4-BK-STK	NB18092001	31.75 mm	15.88 mm	袋和盒	15.88 – 31.75 mm
RNF-100-2-BK-SP	NB18144001	50.8 mm	25.4 mm	Reel	25.4 – 50.8 mm
RNF-100-2-BK-STK	NB18162001	50.8 mm	25.4 mm	袋和盒	25.4 – 50.8 mm
RNF-100-3-BK-SP	NB18284001	76.2 mm	38.1 mm	Reel	38.1 – 76.2 mm
RNF-100-3-BK-STK	NB18302001	76.2 mm	38.1 mm	袋和盒	38.1 – 76.2 mm
RNF-100-4-BK-SP	NB18434001	101.6 mm	50.8 mm	Reel	50.8 – 101.6 mm
RNF-100-4-BK-STK	NB18442001	101.6 mm	50.8 mm	袋和盒	50.8 – 101.6 mm
RNF-100-1/16-BK-STK	NB18742001	1.6 mm	.79 mm	袋和盒	.79 – 1.6 mm
RNF-100-1/4-BK-STK	NB18932001	6.35 mm	3.17 mm	袋和盒	3.17 – 6.35 mm
RNF-100-1/8-BK-STK	NB19162001	3.17 mm	1.57 mm	袋和盒	1.57 – 3.17 mm
RNF-100-3/16-BK-STK	NB19392001	4.74 mm	2.36 mm	袋和盒	2.36 – 4.74 mm
RNF-100-3/32-BK-STK	NB19642001	2.36 mm	1.17 mm	袋和盒	1.17 – 2.36 mm
RNF-100-3/8-BK-BULK-SP	NB22664001	9.5 mm	4.74 mm	Reel	4.74 – 9.5 mm
RNF-100-1-1/2-BK-STK	RNF-100-1-1/2-BK-STK	38.1 mm	19.05 mm	桿	19.05 – 38.1 mm
RNF-100-1-1/4-BK-STK	RNF-100-1-1/4-BK-STK	31.75 mm	15.88 mm	桿	15.88 – 31.75 mm
RNF-100-1/16-BK-80MM	RNF-100-1/16-BK-80MM	1.6 mm	.79 mm	零件	.79 – 1.6 mm
RNF-100-1/2-A1-BK-120MM	RNF-100-1/2-A1-BK-120MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-A1-BK-40MM	RNF-100-1/2-A1-BK-40MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-1.5IN	RNF-100-1/2-BK-1.5IN	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-20.25IN	RNF-100-1/2-BK-20.25IN	12.7 mm	6.35 mm	Box	6.4 – 12.7 mm
RNF-100-1/2-BK-33MM	RNF-100-1/2-BK-33MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-50MM	RNF-100-1/2-BK-50MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-570MM	RNF-100-1/2-BK-570MM	12.7 mm	6.35 mm	Box	6.4 – 12.7 mm
RNF-100-1/2-BK-640MM	RNF-100-1/2-BK-640MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-675MM	RNF-100-1/2-BK-675MM	12.7 mm	6.35 mm	零件	6.4 – 12.7 mm
RNF-100-1/2-BK-FSP	RNF-100-1/2-BK-FSP	12.7 mm	6.35 mm	平滑卷
RNF-100-1/2-BK-FSP-250KFT	RNF-100-1/2-BK-FSP-250KFT	12.7 mm	6.35 mm	Reel	6.4 – 12.7 mm
RNF-100-1/4-BK-1IN	RNF-100-1/4-BK-1IN	6.35 mm	3.17 mm	零件	3.17 – 6.35 mm
RNF-100-1/4-BK-38MM	RNF-100-1/4-BK-38MM	6.35 mm	3.17 mm	零件	3.17 – 6.35 mm
RNF-100-1/4-BK-75MM	RNF-100-1/4-BK-75MM	6.35 mm	3.17 mm	零件	3.17 – 6.35 mm
RNF-100-1/4-BK-SP-SH	RNF-100-1/4-BK-SP-SH	6.35 mm	3.17 mm	Reel	3.17 – 6.35 mm
RNF-100-1/8-BK-2IN	RNF-100-1/8-BK-2IN	3.17 mm	1.57 mm	Box	1.57 – 3.17 mm
RNF-100-1/8-BK-60MM	RNF-100-1/8-BK-60MM	3.17 mm	1.57 mm	Box	1.57 – 3.17 mm
RNF-100-1/8-BK-STK-SH	RNF-100-1/8-BK-STK-SH	3.17 mm	1.57 mm	袋和盒	1.57 – 3.17 mm
RNF-100-2-BK-342MM	RNF-100-2-BK-342MM	50.8 mm	25.4 mm	Box	25.4 – 50.8 mm
RNF-100-2-BK-STK	RNF-100-2-BK-STK	50.8 mm	25.4 mm	桿	25.4 – 50.8 mm
RNF-100-3/16-BK-0.5IN	RNF-100-3/16-BK-0.5IN	4.74 mm	2.36 mm	零件	2.36 – 4.74 mm
RNF-100-3/16-BK-50MM	RNF-100-3/16-BK-50MM	4.74 mm	2.36 mm	零件	2.36 – 4.74 mm
RNF-100-3/16-BK-SP-SH	RNF-100-3/16-BK-SP-SH	4.74 mm	2.36 mm	Reel	2.36 – 4.74 mm
RNF-100-3/4-3X-A1-BK-50MM	RNF-100-3/4-3X-A1-BK-50MM	19.05 mm	9.5 mm	Box	9.5 – 19.05 mm
RNF-100-3/4-A1-BK-30MM	RNF-100-3/4-A1-BK-30MM	19.05 mm	9.5 mm	零件	9.5 – 19.05 mm
RNF-100-3/4-A1-BK-40MM	RNF-100-3/4-A1-BK-40MM	19.05 mm	9.5 mm	零件	9.5 – 19.05 mm
RNF-100-3/4-A1-BK-50MM	RNF-100-3/4-A1-BK-50MM	19.05 mm	9.5 mm	零件	9.5 – 19.05 mm
RNF-100-3/4-BK-2.25IN	RNF-100-3/4-BK-2.25IN	19.05 mm	9.5 mm	Box	9.5 – 19.05 mm
RNF-100-3/4-BK-2.5IN	RNF-100-3/4-BK-2.5IN	19.05 mm	9.5 mm	零件	9.5 – 19.05 mm
RNF-100-3/4-BK-250MM	RNF-100-3/4-BK-250MM	19.05 mm	9.5 mm	Box	9.5 – 19.05 mm
RNF-100-3/4-BK-STK-SH	RNF-100-3/4-BK-STK-SH	19.05 mm	9.5 mm	袋和盒	9.5 – 19.05 mm
RNF-100-3/8-A1-BK-30MM	RNF-100-3/8-A1-BK-30MM	9.5 mm	4.74 mm	零件	4.74 – 9.5 mm
RNF-100-3/8-BK-2.5IN	RNF-100-3/8-BK-2.5IN	9.5 mm	4.74 mm	零件	4.74 – 9.5 mm
RNF-100-3/8-BK-556MM	RNF-100-3/8-BK-556MM	9.5 mm	4.74 mm	零件	4.74 – 9.5 mm
RNF-100-3/8-BK-FSP	RNF-100-3/8-BK-FSP	9.5 mm	4.74 mm	平滑卷
RNF-100-3/8-BK-STK-SH	RNF-100-3/8-BK-STK-SH	9.5 mm	4.74 mm	袋和盒	4.74 – 9.5 mm
RNF-100-MINI-SPL-1/2-BK	RNF-100-MINI-SPL-1/2-BK	12.7 mm	6.35 mm	迷你卷	6.35 – 12.7 mm
RNF-100-MINI-SPL-1/4-BK	RNF-100-MINI-SPL-1/4-BK	6.35 mm	3.17 mm	迷你卷	3.17 – 6.35 mm
RNF-100-MINI-SPL-1/8-BK	RNF-100-MINI-SPL-1/8-BK	3.17 mm	1.57 mm	迷你卷	1.57 – 3.17 mm
RNF-100-MINI-SPL-3/16-BK	RNF-100-MINI-SPL-3/16-BK	4.74 mm	2.36 mm	迷你卷	2.36 – 4.74 mm
RNF-100-MINI-SPL-3/32-BK	RNF-100-MINI-SPL-3/32-BK	2.36 mm	1.17 mm	迷你卷	1.17 – 2.36 mm
RNF-100-MINI-SPL-3/4-BK	RNF-100-MINI-SPL-3/4-BK	19.05 mm	9.5 mm	迷你卷	9.5 – 19.05 mm
RNF-100-MINI-SPL-3/64-BK	RNF-100-MINI-SPL-3/64-BK	1.17 mm	.58 mm	迷你卷	.58 – 1.17 mm
RNF-100-MINI-SPL-3/8-BK	RNF-100-MINI-SPL-3/8-BK	9.5 mm	4.74 mm	迷你卷	4.74 – 9.5 mm

TE集團的Raychem瑞侃的產品是以及自然環境和條件下靠受得了性的代形容詞。Raychem是首個用途稱做“散發電學”的斬新專業軟件常識知識來奠定的產品的品牌，Raychem一產品的在材質小學科學、項目和種植的平臺一直都在是北京環球當先職業。Raychem在航空核工業核工業、新綠色能源車輛、行業主動化、聯系等軟件平臺，Raychem直闡揚出杰出青年靠經得住的功效，然而也在激發注重用。

鄭州市立維創展科技欧美在线一区二区-亚洲欧美综合-欧美国产一区二区-国产欧美一区二区作為一個Raychem瑞侃代理加盟商，具備Raychem瑞侃銜接器現貨黃金庫存盤點，并應具我國國里外勝機銷售渠道、價格多少勝機，追捧管理咨詢。
